XZL‑GDBXG03 square top fixed stainless steel bollard features neat square flat top design, wall thickness 3mm, material 304SS / 316SS stainless steel. This modern security bollard owns abundant dimension choices: diameter 100mm,219mm,254mm,325mm; height 900mm and 1100mm. Clean geometric appearance matches modern plaza, business district and architectural landscape. Solid steel structure delivers stable anti‑collision protection for public traffic separation.


| Product Model | SKU Code | Diameter | Height | Thickness | Material |
| XZL-GDBXG01 | XZL-GDBXG01-D200H1050T3 | 200 | 1050 | 3 | 304SS/316SS |
| XZL-GDBXG01-D300H1050T3 | 300 | 1050 | 3 | 304SS/316SS | |
| XZL-GDBXG02 | XZL-GDBXG02-D114H1050T3 | 114 | 1050 | 3 | 304SS/316SS |
| XZL-GDBXG02-D219H1050T3 | 219 | 1050 | 3 | 304SS/316SS | |
| XZL-GDBXG03 | XZL-GDBXG03-D100H1100T3 | 100 | 1100 | 3 | 304SS/316SS |
| XZL-GDBXG03-D100H900T3 | 100 | 900 | 3 | 304SS/316SS | |
| XZL-GDBXG04 | XZL-GDBXG04-D219H1050T3 | 219 | 1050 | 3 | 304SS/316SS |
| XZL-GDBXG04-D254H1050T3 | 254 | 1050 | 3 | 304SS/316SS | |
| XZL-GDBXG04-D325H1050T3 | 325 | 1050 | 3 | 304SS/316SS | |
| XZL-GDBXG05 | XZL-GDBXG05-D89H900T3 | 89 | 900 | 3 | 304SS/316SS |
| XZL-GDBXG05-D114H1050T3 | 114 | 1050 | 3 | 304SS/316SS | |
| XZL-GDBXG05-D140H1200T3 | 140 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG05-D168H1200T3 | 168 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG05-D220H1200T3 | 220 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG06 | XZL-GDBXG06-D89H900T3 | 89 | 900 | 3 | 304SS/316SS |
| XZL-GDBXG06-D114H1050T3 | 114 | 1050 | 3 | 304SS/316SS | |
| XZL-GDBXG06-D140H1200T3 | 140 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG06-D168H1200T3 | 168 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG06-D220H1200T3 | 220 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG07 | XZL-GDBXG07-D89H900T3 | 89 | 900 | 3 | 304SS/316SS |
| XZL-GDBXG07-D114H1050T3 | 114 | 1050 | 3 | 304SS/316SS | |
| XZL-GDBXG07-D140H1200T3 | 140 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG07-D168H1200T3 | 168 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG07-D220H1200T3 | 220 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG08 | XZL-GDBXG08-D89H900T3 | 89 | 900 | 3 | 304SS/316SS |
| XZL-GDBXG08-D140H900T3 | 140 | 900 | 3 | 304SS/316SS | |
| XZL-GDBXG08-D168H900T3 | 168 | 900 | 3 | 304SS/316SS | |
| XZL-GDBXG08-D220H900T3 | 220 | 900 | 3 | 304SS/316SS | |
| XZL-GDBXG09 | XZL-GDBXG09-D89H900T3 | 89 | 900 | 3 | 304SS/316SS |
| XZL-GDBXG09-D114H900T3 | 114 | 900 | 3 | 304SS/316SS | |
| XZL-GDBXG09-D140H900T3 | 140 | 900 | 3 | 304SS/316SS | |
| XZL-GDBXG09-D165H900T3 | 165 | 900 | 3 | 304SS/316SS | |
| XZL-GDBXG09-D219H1000T3 | 219 | 1000 | 3 | 304SS/316SS | |
| XZL-GDBXG10 | XZL-GDBXG10-D89H1300T3 | 89 | 1300 | 3 | 304SS/316SS |
| XZL-GDBXG10-D114H1300T3 | 114 | 1300 | 3 | 304SS/316SS | |
| XZL-GDBXG10-D140H1300T3 | 140 | 1300 | 3 | 304SS/316SS | |
| XZL-GDBXG10-D165H1300T3 | 165 | 1300 | 3 | 304SS/316SS |
* Neat Square Top Styling: Modern square top design fits minimalist architectural landscape projects.
* Rich Dimension Choices: Multiple diameter and height specifications to match different site layout demands.
* 3mm Heavy‑thick Stainless Steel Body: Solid structure provides stable anti‑collision performance as traffic bollard.
* Two Stainless Steel Grade: 304SS for general outdoor, 316SS for coastal anti‑corrosion performance.
* Premium Brushed Surface Treatment: Anti‑rust for long‑term outdoor plaza and pavement usage.
* Optional Reflective Film: For night traffic warning to improve site safety.

Square‑top fixed stainless steel bollard fits city plaza, business pedestrian street, museum surrounding, commercial building exterior, scenic spot, city square, residential pedestrian access and architectural landscape projects. Modern square‑top appearance coordinates well with minimalist building style.


Chengdu Xinzhonglian Traffic Facilities Co.,Ltd. focusing on the field of traffic facilities, is a large and medium-sized traffic facilities production enterprise integrating research and development, production, processing and sales. It has passed the mass production certificate of traffic engineering products of the Ministry of Communications, and is one of the early enterprises engaged in the research and production of high-grade traffic safety products in China. We have our own factory in Chengdu, covering an area of about 33,340 square meters, with an annual output of 48,000 tons. We have 5 senior technicians, 8 intermediate technicians and 12 junior technicians. The total number of employees in the factory is about 200. We have made great progress. At present, we have advanced production equipment, perfect technological process, strict quality control system and accurate testing means. Our main products include is flexible Bollard, stainless steel fixed Bollard, removable bollard, solar light bollard,manual lifting bollard, semi-automatic rising bollard and hydraulic automatic bollard.





* Custom non‑standard height for square top fixed stainless steel security bollard
* Optional 304SS or 316SS stainless steel material for inland or coastal environment
* Custom outer diameter beyond standard size list for heavy‑duty anti‑collision project
* Custom laser engraved brand logo and project code on bollard body
* Custom specification and mounting position of reflective warning film
* Custom base plate size and bolt hole distribution for site installation condition
* Provide project‑specific CAD drawings and complete installation guidance
* Support OEM ODM bulk orders with custom export packaging for overseas clients
Q1: What sizes are available for XZL‑GDBXG03 square top fixed bollard
A1: Diameter 100mm,219mm,254mm,325mm; height 900mm and 1100mm, wall thickness 3mm.
Q2: What scenarios suit this square‑top stainless steel security bollard
A2: It is widely adopted for modern plaza, pedestrian street and commercial building landscape projects.
Q3: How to choose between 304SS and 316SS for this traffic bollard
A3: 304SS for inland city projects; 316SS for seaside, high‑salt fog coastal environment.
Q4: What installation modes for this steel safety bollard
A4: Surface bolt‑down mounting and underground embedded installation both supported.
Q5: Is reflective film pre‑installed on this driveway bollard
A5: Reflective film belongs to optional accessory, we can assemble upon customer request.
Q6: Can large‑diameter version 325mm bollard take heavy vehicle impact
A6: 3mm thick large‑diameter fixed bollard achieves enhanced anti‑collision capacity for heavy‑load projects.
Q7: Can I get sample for dimension and surface checking
A7: Sample is available for project confirmation.
Q8: Can we adjust surface finish for this pavement bollard
A8: Brushed, mirror polish and other custom surface treatments are acceptable.
