XZL‑GDBXG02 fixed stainless steel bollard adopts smooth dome top design, wall thickness 3mm, material 304SS or 316SS stainless steel. This dome top security bollard features rounded safe top without sharp corner, ideal for high‑flow pedestrian public zones. Standard height 1050mm, diameter 114mm and 219mm. Brushed stainless steel surface combines safety and modern appearance for city street and commercial landscape projects.


| Product Model | SKU Code | Diameter | Height | Thickness | Material |
| XZL-GDBXG01 | XZL-GDBXG01-D200H1050T3 | 200 | 1050 | 3 | 304SS/316SS |
| XZL-GDBXG01-D300H1050T3 | 300 | 1050 | 3 | 304SS/316SS | |
| XZL-GDBXG02 | XZL-GDBXG02-D114H1050T3 | 114 | 1050 | 3 | 304SS/316SS |
| XZL-GDBXG02-D219H1050T3 | 219 | 1050 | 3 | 304SS/316SS | |
| XZL-GDBXG03 | XZL-GDBXG03-D100H1100T3 | 100 | 1100 | 3 | 304SS/316SS |
| XZL-GDBXG03-D100H900T3 | 100 | 900 | 3 | 304SS/316SS | |
| XZL-GDBXG04 | XZL-GDBXG04-D219H1050T3 | 219 | 1050 | 3 | 304SS/316SS |
| XZL-GDBXG04-D254H1050T3 | 254 | 1050 | 3 | 304SS/316SS | |
| XZL-GDBXG04-D325H1050T3 | 325 | 1050 | 3 | 304SS/316SS | |
| XZL-GDBXG05 | XZL-GDBXG05-D89H900T3 | 89 | 900 | 3 | 304SS/316SS |
| XZL-GDBXG05-D114H1050T3 | 114 | 1050 | 3 | 304SS/316SS | |
| XZL-GDBXG05-D140H1200T3 | 140 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG05-D168H1200T3 | 168 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG05-D220H1200T3 | 220 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG06 | XZL-GDBXG06-D89H900T3 | 89 | 900 | 3 | 304SS/316SS |
| XZL-GDBXG06-D114H1050T3 | 114 | 1050 | 3 | 304SS/316SS | |
| XZL-GDBXG06-D140H1200T3 | 140 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG06-D168H1200T3 | 168 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG06-D220H1200T3 | 220 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG07 | XZL-GDBXG07-D89H900T3 | 89 | 900 | 3 | 304SS/316SS |
| XZL-GDBXG07-D114H1050T3 | 114 | 1050 | 3 | 304SS/316SS | |
| XZL-GDBXG07-D140H1200T3 | 140 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG07-D168H1200T3 | 168 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG07-D220H1200T3 | 220 | 1200 | 3 | 304SS/316SS | |
| XZL-GDBXG08 | XZL-GDBXG08-D89H900T3 | 89 | 900 | 3 | 304SS/316SS |
| XZL-GDBXG08-D140H900T3 | 140 | 900 | 3 | 304SS/316SS | |
| XZL-GDBXG08-D168H900T3 | 168 | 900 | 3 | 304SS/316SS | |
| XZL-GDBXG08-D220H900T3 | 220 | 900 | 3 | 304SS/316SS | |
| XZL-GDBXG09 | XZL-GDBXG09-D89H900T3 | 89 | 900 | 3 | 304SS/316SS |
| XZL-GDBXG09-D114H900T3 | 114 | 900 | 3 | 304SS/316SS | |
| XZL-GDBXG09-D140H900T3 | 140 | 900 | 3 | 304SS/316SS | |
| XZL-GDBXG09-D165H900T3 | 165 | 900 | 3 | 304SS/316SS | |
| XZL-GDBXG09-D219H1000T3 | 219 | 1000 | 3 | 304SS/316SS | |
| XZL-GDBXG10 | XZL-GDBXG10-D89H1300T3 | 89 | 1300 | 3 | 304SS/316SS |
| XZL-GDBXG10-D114H1300T3 | 114 | 1300 | 3 | 304SS/316SS | |
| XZL-GDBXG10-D140H1300T3 | 140 | 1300 | 3 | 304SS/316SS | |
| XZL-GDBXG10-D165H1300T3 | 165 | 1300 | 3 | 304SS/316SS |
* Safe Dome Top Fixed Stainless Steel Bollard: Rounded dome top avoids sharp‑edge injury for crowded pedestrian public areas.
* 3mm Thick Heavy‑Duty Steel Body: Stable solid structure provides reliable anti‑collision performance as traffic safety bollard.
* Two‑grade Stainless Steel Material: 304SS for general outdoor usage, 316SS for seaside anti‑rust requirement.
* Multiple Diameter Selection: 114mm and 219mm diameter for different load‑bearing project requirements.
* Brushed Stainless Steel Surface: Anti‑fingerprint, anti‑oxidation for long‑term outdoor street application.
* Optional Reflective Warning Film: Improve night visibility for road and pavement safety reminder.

This dome‑top fixed security bollard applies to city sidewalk, pedestrian street, school gateway, hospital entrance, residential community driveway, retail store front, city park and public walkway. Rounded dome top greatly reduces collision injury risk in high‑pedestrian‑flow public sites.


Chengdu Xinzhonglian Traffic Facilities Co.,Ltd. focusing on the field of traffic facilities, is a large and medium-sized traffic facilities production enterprise integrating research and development, production, processing and sales. It has passed the mass production certificate of traffic engineering products of the Ministry of Communications, and is one of the early enterprises engaged in the research and production of high-grade traffic safety products in China. We have our own factory in Chengdu, covering an area of about 33,340 square meters, with an annual output of 48,000 tons. We have 5 senior technicians, 8 intermediate technicians and 12 junior technicians. The total number of employees in the factory is about 200. We have made great progress. At present, we have advanced production equipment, perfect technological process, strict quality control system and accurate testing means. Our main products include is flexible Bollard, stainless steel fixed Bollard, removable bollard, solar light bollard,manual lifting bollard, semi-automatic rising bollard and hydraulic automatic bollard.





* Custom working height for dome top fixed stainless steel bollard out of standard 1050mm
* Selectable 304SS or 316SS stainless steel material for different outdoor corrosion environment
* Custom outer diameter size to satisfy special anti‑collision project specification
* Custom laser engraved logo and project serial number on bollard body
* Custom size color and sticking position of reflective warning film
* Custom base plate dimension and bolt hole layout for surface installation
* Supply custom CAD construction drawings and installation instruction files
* Accept OEM ODM bulk project orders with custom export carton packaging
Q1: What is the advantage of dome top fixed stainless steel bollard
A1: Smooth rounded dome top removes sharp corners, greatly lower injury risk for pedestrian‑heavy public places.
Q2: What diameter options for XZL‑GDBXG02 traffic bollard
A2: Standard diameter 114mm and 219mm, wall thickness 3mm, default height 1050mm.
Q3: Which material should I choose for seaside driveway bollard
A3: Select 316SS stainless steel version for coastal high‑humidity salt‑spray environment.
Q4: What installation ways for this steel safety bollard
A4: Bolt‑on surface mounting or inground embedded installation both available.
Q5: Does this fixed bollard come with reflective film
A5: Reflective film is optional part, you can add this accessory per project needs.
Q6: Can this security bollard be used for school perimeter protection
A6: Yes, dome‑top safe design is highly recommended for school and kid‑frequented public zones.
Q7: Can I order sample for project test
A7: Sample service is supported for buyer evaluation before large‑volume order.
Q8: Is surface finish adjustable for this pavement bollard
A8: Standard brushed finish, mirror polish or other surface process can be customized.
