Anti-Collision Hydraulic Automatic Lifting Bollard

Anti-Collision Hydraulic Automatic Lifting Bollard

Anti-Riot Anti-Collision Hydraulic Automatic Lifting Bollard Adopts Full Steel Integrated Reinforced Structure. The Bollard Body Is Made Of 316L Stainless Steel Thick Plate With Wall Thickness Of 10-12mm, Built-In High-Strength Anti-Collision Mandrel And Anti-Riot Sealing Components, With Impact Resistance Grade Of 80 Tons, Capable Of Withstanding Malicious Collision And Impact Damage From Heavy Vehicles. Equipped With Servo Hydraulic Drive System, Lifting Time Is 1.2-3 Seconds, The Lifting Process Is Stable Without Jitter, With Dual Pressure Holding And Anti-Fall Locking Functions. Protection Grade Reaches IP68, Equipped With Anti-Pry Alarm And Illegal Impact Warning Modules, Supporting Real-Time Linkage With Security Platforms, Monitoring And Alarm Systems. Adapting To Extreme Environments From -45℃ To +75℃, Widely Used In High Security Level Venues, Customizable Anti-Riot Accessories And Intelligent Control Modes To Build A Comprehensive Security Line.

Anti-Riot Anti-Collision Hydraulic Automatic Lifting Bollard Adopts Modular Design, Balancing High-Strength Protection And Economy. Compared With Traditional Anti-Riot Bollards, The Construction Period Is Shortened By 35% And Maintenance Cost Is Reduced By 40%. Integrated Hydraulic Movement Built-In Design, No Exposed Oil Pipes And Wires, Effectively Avoiding Malicious Damage. Single Bollard Operates Independently, Failures Do Not Affect Each Other, And Later Maintenance Does Not Require Overall Disassembly. Equipped With Power Failure Emergency Manual Release Function To Ensure Fire Access And Emergency Passage Needs. Supports Multiple Control Methods Such As Card Swiping, Face Recognition And Remote Control, Can Be Directly Connected To Existing Security Systems Without Additional Transformation. Provides Graded Customization Solutions, The Basic Version Meets Routine Anti-Riot Needs, And The Upgraded Version Strengthens Anti-Collision Performance, Adapting To Scenarios With Different Budgets And Security Levels.

Introduction

Anti-Riot Anti-Collision Hydraulic Automatic Lifting Bollard Is Specifically Designed For High-Risk Security Venues Such As Prisons, Embassies, Government Agencies, Large Venues And Anti-Terrorism Checkpoints, Providing Targeted Vehicle Management And Anti-Riot Protection Solutions. Full Steel Reinforced Shell With Anti-Pry Locks And Impact Buffer Structure Can Effectively Resist Illegal Behaviors Such As Vehicle Collision And Violent Prying. After Triggering An Abnormality, It Immediately Links With The Alarm System And Synchronously Pushes Early Warning Information. Fast Lifting Speed, Suitable For Rapid Management In Crowded Areas With People And Vehicles, Silent Operation Design Does Not Disturb The Normal Order Of The Venue. Strong Scenario-Based Customization Capability: Prison Version Adds Anti-Climbing Devices And High-Voltage Warnings, Embassy Version Strengthens Concealed Installation And Linked Security, Venue Version Is Equipped With LED Warning Lights And Reflective Markings, Fully Adapting To Security Needs Of Different Venues.

Focusing On High-Security Scenario Needs, This Product Provides Comprehensive Anti-Riot And Anti-Collision Customization Services, Accurately Matching Protection Standards Of Different Venues:

1. Structure Customization Bollard Diameter, Height And Wall Thickness Can Be Customized, Supporting Alloy Steel Material Upgrade, Impact Resistance Grade Adjustable From 40 To 120 Tons According To Needs, Meeting Different Security Level Specifications.

2. Anti-Riot Accessories Customization Can Add Anti-Climbing Spikes, High-Voltage Warning Devices, Anti-Pry Locks, Impact Buffers And Bulletproof Observation Windows To Strengthen Comprehensive Anti-Riot Capabilities.

3. Warning & Appearance Customization Full Range Of RAL Colors Optional, Supporting Laser Engraved LOGO And Custom Warning Text, Equipped With LED Warning Lights And Reflective Strips, Balancing Warning Performance And Aesthetics.

4. Function Customization Custom Built-In Heating/Cooling Modules, Remote Linkage Modules And Automatic Alarm Push Functions, Adapting To Extreme Climates And Intelligent Security Systems.

5. Installation Customization Supporting Concealed, Embedded And Mobile Installation, Providing Foundation Reinforcement Solutions, Adapting To Different Construction Conditions And Aesthetic Needs Of Venues.

6. System Docking Customization Adapting To Protocols Of Overseas Mainstream Security Platforms, Customizing Interface Modules To Achieve Seamless Linkage With Monitoring, Alarm And Access Control Systems.

SPECIFICATIONS

Collision Resistance Level (ASTM)	Bollard Specification (Diameter × Lift Height)	Material	Wall Thickness	Embedded Depth	Lifting Speed	Working Pressure	Protection Level
M50/P1 (Vehicle weight: 2270kg, Speed: 80km/h, Impact energy: 500kJ)	168mm × 600mm	304/316 Stainless Steel	8mm - 10mm	800mm - 1100mm	3s - 5s	10MPa - 15MPa	IP67
	219mm × 600mm	304/316 Stainless Steel	10mm - 12mm	800mm - 1100mm	3s - 5s	10MPa - 15MPa	IP67
	273mm × 600mm	304/316 Stainless Steel	12mm - 15mm	800mm - 1100mm	4s - 6s	12MPa - 18MPa	IP67
M30/P1 (Vehicle weight: 2270kg, Speed: 64km/h, Impact energy: 300kJ)	168mm × 600mm	304 Stainless Steel	6mm - 8mm	800mm - 1100mm	3s - 5s	8MPa - 12MPa	IP67
	219mm × 600mm	304 Stainless Steel	8mm - 10mm	800mm - 1100mm	3s - 5s	8MPa - 12MPa	IP67
	273mm × 600mm	304 Stainless Steel	10mm - 12mm	800mm - 1100mm	4s - 6s	10MPa - 15MPa	IP67
M40/P2 (Vehicle weight: 4540kg, Speed: 48km/h, Impact energy: 400kJ)	168mm × 600mm	316 Stainless Steel	10mm - 12mm	800mm - 1100mm	3s - 5s	12MPa - 18MPa	IP68
	219mm × 600mm	316 Stainless Steel	12mm - 14mm	800mm - 1100mm	3s - 5s	12MPa - 18MPa	IP68
	273mm × 600mm	316 Stainless Steel	14mm - 16mm	800mm - 1100mm	4s - 6s	15MPa - 20MPa	IP68
Standard Anti-Riot (Non-ASTM, Light-Duty)	114mm × 600mm	Q235 Steel (Powder-Coated)	4mm - 6mm	750mm - 850mm	4s - 6s	6MPa - 10MPa	IP65
	168mm × 600mm	Q235 Steel (Powder-Coated)/304 Stainless Steel	6mm - 8mm	750mm - 850mm	4s - 6s	6MPa - 10MPa	IP65
	219mm × 600mm	Q235 Steel (Powder-Coated)/304 Stainless Steel	8mm - 10mm	750mm - 850mm	4s - 6s	8MPa - 12MPa	IP65

KEY FEATURES

◆ High-Strength Anti-Riot & Anti-Collision 316L Stainless Steel + 10-12mm Wall Thickness, 80-Ton Impact Resistance, Built-In Anti-Collision Mandrel And Buffer Structure, Resisting Heavy Vehicle Collision And Violent Damage

◆ Full Steel Reinforced Structure Integrated Welding Process, Anti-Pry, Anti-Climbing, Anti-Cutting, Preventing Illegal Disassembly And Damage

◆ Servo Hydraulic Drive Lifting Time 1.2-3 Seconds, Stable Without Jitter, Dual Pressure Holding Design To Prevent Accidental Falling

◆ Intelligent Security Linkage Supporting Linkage With Monitoring, Alarm And Access Control Systems, Automatic Alarm And Information Push In Abnormal Situations

◆ High Protection & Adaptability IP68 Protection Grade, Operating Temperature From -45℃ To +75℃, Adapting To Extreme Climates And Complex Environments

◆ Emergency Guarantee Function Manual/Auto Descending When Power Off, Ensuring Unobstructed Emergency Access, Meeting Fire Protection Standards

◆ Modular Design Single Bollard Operates Independently, Convenient Maintenance, Low Maintenance Cost, Extending Equipment Service Life

◆ Multi-Mode Control Remote Control, Card Swiping, Face Recognition, License Plate Recognition, APP Control, Adapting To Different Management Scenarios

◆ Scenario-Based Customization Supporting Customization Of Anti-Riot Accessories, Warning Signs And Installation Methods, Adapting To Different Security Level Needs

◆ Safety Early Warning Mechanism Automatic Alarm For Illegal Collision And Prying, Synchronous Linkage With Security Platform, Improving Emergency Response Efficiency

APPLICATION

◆ Prisons/Detention Centers Preventing Escape Collision, Managing Incoming And Outgoing Vehicles, Linking With Security Systems For 24-Hour Early Warning

◆ Embassies/Consulates Resisting Malicious Collision And Terrorist Attacks, Strengthening Peripheral Security, Ensuring Safety Of Personnel And Facilities

◆ Government Agencies/Military Units Managing Important Access, Preventing Illegal Vehicle Intrusion, Improving Security Level Of Core Areas

◆ Large Venues/Exhibition Centers Rapidly Managing Traffic During Events And Exhibitions, Preventing Malicious Collision, Ensuring On-Site Order

◆ Anti-Terrorism Checkpoints/Border Crossings Intercepting Illegal Vehicles, Cooperating With Security Inspection Equipment, Building Anti-Terrorism And Anti-Riot Lines

◆ Financial Escort Channels Protecting The Safety Of Cash Escort Vehicles In And Out, Preventing Robbery And Collision, Linking With Alarm Systems

◆ Nuclear Power Plants/Energy Bases Managing Vehicles In High-Risk Areas, Preventing Accidental Collision And Malicious Damage, Ensuring Production Safety

◆ Airport/High-Speed Railway Station VIP Channels Security Management Of Exclusive Areas, Preventing Unauthorized Vehicle Intrusion, Improving Travel Safety

◆ Key Schools/Research Institutes Anti-Riot Protection Of Core Areas, Preventing Malicious Vehicle Intrusion, Ensuring Safety Of Teachers, Students And Research

◆ High-End Hotels/Commercial Complexes Managing Traffic In VIP Areas, Balancing Security And Aesthetics, Enhancing Venue Quality

FAQ

Q1: What International Standards Does The Anti-Riot And Anti-Collision Level Of This Product Comply With?

A1: Complying With ASTM F2656-07 International Anti-Collision Standard, The 80-Ton Impact Resistance Can Withstand Heavy Vehicle Collision At 150km/h Speed, And Also Meets GB/T 37584-2019 Anti-Riot Bollard Technical Requirements, Adapting To Global High-Security Scenarios.

Q2: What Anti-Riot Related Accessories Can Be Customized?

A2: Customizable Anti-Climbing Spikes, High-Voltage Warning Devices, Anti-Pry Locks, Impact Buffers, Concealed Installation Bases, And Can Also Add Custom Anti-Riot Accessories Such As Bulletproof Glass Observation Windows And Sound-Light Alarm Modules According To Requirements.

Q3: What Is The Production Cycle And Transportation Method For Customized Products?

A3: Standard Anti-Riot Version Shipped Within 7-10 Days, Deep Customized Version (With Special Accessories) Delivered Within 20-30 Days; Supporting Sea And Air Transportation, Providing Fumigation Certificates And Customs Declaration Documents, And Can Assist In Connecting With Overseas Installation Teams.

Q4: What Does The Product Warranty And After-Sales Support Cover?

A4: 3-Year Warranty For Main Structure, 2-Year Warranty For Hydraulic System, Providing Maintenance Parts And Technical Support For Life; 24-Hour Global After-Sales Hotline, Offering Remote Guidance Or Dispatching Engineers For On-Site Maintenance (Overseas Travel Expenses To Be Borne By The Customer).

Q5: Does It Support Linkage With Overseas Security Systems?

A5: Yes, The Product Reserves International Universal Interfaces (RS485/Ethernet), Can Be Connected To Global Mainstream Security Platforms Such As Hikvision And Dahua, And Can Also Conduct Protocol Adaptation Customization According To Overseas Customers' Existing Systems.

Q6: What Are The Product Weight And Installation Requirements?

A6: The Weight Of A Single Standard Bollard Is 280-350kg, And The Enhanced Version Is 400-500kg; Reinforced Concrete Foundation Is Required, Installation Depth Is 800-1000mm, Providing Detailed Installation Drawings And Video Guidance, 2 People Can Install 6 Bollards In 2 Days.

Q7: Can Anti-Riot And Anti-Collision Performance Test Reports Be Provided?

A7: Can Provide Anti-Impact, Anti-Pry And Protection Level Test Reports Issued By Third-Party Authoritative Organizations (SGS, CTI), And Support Applying For Local Certifications (Such As CE, FCC, UL) According To Overseas Customers' Requirements.

Q8: Are Special Configurations Required For Use In Extremely Cold Or High-Temperature Areas?

A8: Can Customize Built-In Heating System (Adapting To Extremely Cold Areas Below -45℃) And High-Temperature Heat Dissipation Module (Adapting To High-Temperature Environments Above +75℃), Ensuring Stable Operation Of The Hydraulic System In Extreme Climates.
